- Battery
- Spektrum Smart Technology Makes Charging and Maintaining Batteries Easy
- Integrated Microship Stores Unique Parameters for Each Battery
- IC3 and IC5 Connectors are Compatible with EC3 and EC5
- Save Time and Hassle, while Improving Battery Life
- Smart Discharge Allows Batteries to Automatically Discharge to a Safe Voltage
- Charger
- Recognizes unique Smart battery data for safe, easy charging
- Can also be used to charge batteries without Smart technology
- 50 watts of charging power, up to 5 amps of charge current
- Compact, easily portable design
- One-button interface and simple to understand charging indicator
- Adaptable for AC power input (includes AC to 20V DC power supply)
- Quiet internal cooling fan maintains a safe, efficient operating temperature
- Supports charging LiPo, Lilon, LiHV, and NiMH battery types
- Accepts future Smart technology updates
- Battery
- Type: Smart LiPo
- Capacity: 2200 mAh
- Voltage: 11.1V
- Connector Type: IC3
- Cell Size: 3.7V
- Number of Cells: 3
- Weight: 0.40 lbs. (180g)
- Dimensions (WxLxH): 4.2 x 1.3 x 0.9 in. (107 x 34 x 24mm)
- Application: Aircraft
- Maximum Continuous Discharge: 30C
- Charger
- Amp Meter: No
- Application: Battery Charger for Electric Powered RC Vehicles and Aircraft
- Battery Balance Connector: JST-XH
- Battery Temperature Monitoring: No
- Battery Type: LiPo (3.7V per cell)
- Connector Type: IC3
- Cooling Method: Fan
- Discharge: Yes
- Input Voltage: 100-240V AC
- Integrated Balancing: Yes – Internal Balancer & Internal Adapter
- Low Input Voltage Protection: Yes
- Maximum Charge Rate: 17.4V, 5A, 50W
- Normal/Standard Charge Current: 1.0 – 5.0A
- Number of Cells: 2-4S LiPo, LiFe LiHV, LiFe, 2-12 cell NiMH
- Output: 5A
- Output Connector: IC3 (compatible with EC3)
- Over Current Protection: Yes
- Peak Detection: Yes
- Product Height: 1.12″ (28.5mm)
- Product Length: 2.5″ (65mm)
- Product Weight: 2.2oz (63g)
- Product Width: 1.9″ (49mm)
- Programmable: No
- Reverse Polarity Protection: Yes
- Safety Timer: Yes
- Search Keywords: smartspmx_charger
- Selectable Charge Rate: Yes
- Shape: Rectangular
- Short Circuit Protection: Yes
- Technology: Smart
- Thermal Protection: Yes
- Voltage Meter: No
