Specifications
Stator Diameter: 25.0 mm (0.98 in)
Stator Thickness: 20.0 mm (0.79 in)
No. of Stator Arms: 12
No. of Magnet Poles: 10
Motor Wind: 8 Turn Delta
Motor Wire: 11-Strand 0.25mm
Motor Kv: 1880 RPM / Volt
No-Load Current (Io): 2.25 Amps @ 10 volts
Motor Resistance (Rm): 0.026 Ohms
Max Continuous Current: 38 Amps
Max Continuous Power: 800 Watts
Weight: 104 Grams (3.64oz)
Outside Diameter: 31.5 mm (1.24 in)
Shaft Diameter: 3.5 mm (0.14 in)
Body Length: 39.6 mm (1.56 in)
Overall Shaft Length: 57.5 mm (2.46 in)
Max LiPo Cell: 6s
Motor Timing: 5°
Drive Frequency: 8kHz
This product was added to our catalog on January 12, 2018
