Lynx Heli H0988UHS-I Blue Arrow Digital Tail Servo

The Lynx Blue Arrow H0988UHS-I is all metal gear digital Micro 3D heli ultra-high speed tail servo, featuring a narrow 760uS pulse width for incredible performance.

Features:

• Digital circuit
• Fast response and excellent output performance
• Top ball bearing
• Torque ouput is more stable and smooth
• 0714 coreless motor
• Torque and speed increased
• All metal gears
• Wide working voltage 3.5-7.4V

Specifications:
Working frequency: 760us/333Hz
Torque: 1.10kg.cm @4.8V; 1.40kg.cm @ 6.0V
Speed: 0.036sec/60°@4.8V; 0.033sec/60°@6.0V
Ball Bearings: Top ball bearing
Motor: 7mm coreless
Gear: All metal gears
Connector Type: JST-ZHR (1.5mm)
Length/Width/Height: 23×11.6×22.5mm
Weight: 9.0g
Operating Voltage: 3.5-7.4V

This product was added to our catalog on November 26, 2018
