KST X12-508 Micro Digital Metal Gear Servo

The KST X12-508 Micro Digital Servo is an ideal choice for Cyclic applications on 325-420mm helicopters that use micro servos such as the Align T-Rex 450, T-Rex 470L, MSH Protos 380, SAB Goblin 380, and Goblin 420 helicopters. Additionally these can be used in other R/C applications which are correctly sized dimensionally, and offer the correct torque/speed ratings when needed.

Features:

• Micro size aluminum case
• Full metal gears
• Dual ball bearings
• HV compatible
• Lightning fast
• Coreless motor

Specifications:
Operating Voltage: 4.8-8.4V
Size: 23x12x27.5mm
Torque: 4.2kg.cm @ 6.0V; 6.2kg.cm @ 8.4V
Speed: 0.09sec/60° @ 6.0V; 0.07sec/60° @ 8.4V
Weight: 20g
Working Frequency: 1520us/333Hz, 800us – 2200us
Motor: Coreless
Ball Bearing: 2BB

This product was added to our catalog on October 4, 2017
